This manual provides a comprehensive guide for the Heath Zenith Motion Sensor Light Dual Brite‚ covering installation‚ features‚ and troubleshooting․ It ensures optimal use of the device․
1․1 Overview of the Heath Zenith Dual Brite Motion Sensor Light
The Heath Zenith Dual Brite Motion Sensor Light is a versatile outdoor lighting solution designed to enhance security and convenience․ It features dual brightness settings‚ automatic shut-off‚ and a photocell to disable daylight operation․ The system includes an adjustable ON-TIME switch for customizing light duration and a Dual Brite timer for dimming․ Its energy-efficient design meets ENERGY STAR guidelines when configured properly․
1․2 Importance of Reading the Manual
Reading the manual ensures proper installation‚ operation‚ and troubleshooting of the Heath Zenith Dual Brite Motion Sensor Light․ It provides essential instructions for setting up features like the Dual Brite timer and ON-TIME switch‚ optimizing energy efficiency‚ and understanding maintenance requirements․ Adhering to the guidelines helps maximize performance‚ safety‚ and longevity of the product‚ while also ensuring compliance with ENERGY STAR standards for energy savings․
Installation and Setup
Mount the sensor‚ wire the control‚ and test the system․ Follow manual instructions for optimal setup‚ ensuring proper function and energy efficiency․ A 1-minute warm-up period is required after installation․
2․1 Mounting the Motion Sensor Light
Mounting the Heath Zenith Dual Brite Motion Sensor Light involves securing the fixture to a junction box using the provided mounting strap and screws․ Ensure the fixture is level and firmly attached․ The plastic hanger can assist in holding the fixture while wiring․ All necessary hardware is included for a secure installation․ Follow the manual’s instructions for proper placement and alignment to ensure optimal motion detection and lighting performance․
2․2 Wiring the Light Control
Wiring the Heath Zenith Dual Brite Motion Sensor Light requires turning off the power at the circuit breaker․ Connect the black wire to the black wire of the existing fixture‚ the white wire to the white wire‚ and the copper ground wire to the grounding terminal․ Use the provided wire connectors for secure connections․ After wiring‚ turn the power back on and test the light to ensure proper functionality․ Always follow safety guidelines and local electrical codes․
Operational Features
The Heath Zenith Dual Brite Motion Sensor Light features a Dual Brite Timer‚ motion sensing‚ and automatic shut-off․ It includes a photocell for daylight sensing and an LED indicator for motion detection‚ ensuring energy-efficient operation and reliable performance․
3․1 Dual Brite Timer Functionality
The Dual Brite Timer offers customizable settings‚ with the light operating at half brightness for a selected duration (off‚ 3 hours‚ 6 hours‚ or until dawn)․ When motion is detected‚ the light switches to full brightness for a user-defined period (1‚ 5‚ or 20 minutes)‚ then returns to dim mode․ This feature enhances energy efficiency while providing ample illumination when needed․
3․2 Motion Sensing and Automatic Shut-Off
The Heath Zenith Dual Brite Motion Sensor Light features advanced motion sensing technology that detects movement and automatically activates the light․ After the selected ON-TIME period (1‚ 5‚ or 20 minutes)‚ the light shuts off to conserve energy․ The built-in photocell ensures the light remains off during daylight hours‚ while an LED indicator confirms motion detection‚ day or night‚ ensuring reliable and efficient operation․
Modes of Operation
The Heath Zenith Dual Brite Motion Sensor Light operates in two modes: Auto and Manual․ Auto mode activates the light via motion sensing‚ while Manual mode allows continuous operation‚ offering flexibility for different lighting needs․
4․1 Auto Mode vs․ Manual Mode
Auto Mode activates the light automatically when motion is detected‚ using the photocell to ensure operation only during darkness․ Manual Mode allows for continuous lighting operation‚ bypassing motion detection․ The On-Time switch sets the duration for full brightness in Auto Mode․ Manual Mode is activated by toggling the light switch off and on quickly‚ providing flexibility for user preference․
4․2 Switching Between Modes
Switching between Auto and Manual modes is straightforward․ To toggle between modes‚ flip the light switch off for one second and then back on․ This simple action allows seamless transitions based on user preference․ If confused during mode switching‚ turning the power off for one minute and then back on resets the control to default Auto mode‚ ensuring proper functionality and ease of use for the user․
Troubleshooting Common Issues
Troubleshooting common issues with the Heath Zenith Dual Brite Motion Sensor Light involves checking sensor alignment‚ ensuring proper wiring‚ and verifying mode settings․ Resetting the system by flipping the switch off and on can resolve many problems․ Refer to the manual for detailed solutions to ensure optimal performance and address specific malfunctions effectively․
5․1 Light Not Turning On
If the light fails to turn on‚ ensure the Dual Brite switch is not set to OFF‚ as this disables dim mode․ Verify the ON-TIME switch is set to 1‚ 5‚ or 20 minutes․ Check if the system is in TEST mode‚ which might prevent normal operation․ Ensure the sensor is properly aligned and free from obstructions․ Finally‚ confirm the power source is stable and all connections are secure to resolve the issue effectively․
5․2 Motion Sensor Not Detecting Movement
If the motion sensor isn’t detecting movement‚ ensure it has completed its 1-minute warm-up period after power-up․ Check that the sensor is properly aligned and free from obstructions․ Verify the Dual Brite switch is in the correct position and not disabled․ Also‚ ensure the sensor’s range and angle are adjusted appropriately for your space․ If issues persist‚ consult the manual for reset or calibration instructions to restore functionality․
Technical Specifications
The Heath Zenith Dual Brite features a detection range of up to 70 ft․‚ a 240-degree sensing angle‚ and supports up to 300 watts of electrical load․ Energy Star compliant when Dual Brite is off and ON-TIME is set to 1 or 5 minutes․
6․1 Detection Range and Sensing Angle
The Heath Zenith Dual Brite motion sensor offers a detection range of up to 70 feet (21 meters) and a wide sensing angle of 240 degrees․ This ensures comprehensive coverage for detecting motion in various settings‚ such as driveways‚ porches‚ or yards․ The sensor’s range can be optimized with the optional Range Boost feature‚ enhancing detection capabilities in larger areas․ The wide-angle sensing ensures minimal blind spots‚ providing reliable security lighting solutions․
6․2 Electrical Load and Compatibility
The Heath Zenith Dual Brite motion sensor light is compatible with 120-volts AC power systems․ It supports a maximum electrical load of 300 watts for incandescent bulbs‚ with each socket accommodating up to 150 watts․ The device is designed to work seamlessly with a variety of bulb types‚ ensuring energy efficiency and compatibility․ This feature makes it suitable for both residential and commercial lighting needs‚ providing reliable performance across different setups․
Maintenance and Care
Regular maintenance ensures optimal performance; Clean the sensor and light with a soft cloth to avoid scratching․ Replace bulbs as needed with correct wattage specifications․
7․1 Cleaning the Sensor and Light
Regularly clean the sensor and light with a soft‚ dry cloth to ensure proper function․ Avoid harsh chemicals or abrasive materials that may damage surfaces․ For stubborn dirt‚ lightly dampen the cloth with water․ Always turn off the power before cleaning to prevent electrical issues․ Ensure the sensor is free of debris for accurate motion detection․ Replace any damaged or worn-out parts promptly to maintain performance․
7․2 Replacing Bulbs
To replace bulbs‚ turn off power at the circuit breaker․ Allow bulbs to cool‚ then carefully remove them using gloves to avoid oil residue․ Install new bulbs‚ ensuring they are compatible with the Dual Brite system and meet the wattage specifications․ Reassemble and test the light․ Regular bulb replacement maintains optimal performance and energy efficiency․
Energy Efficiency
The Heath Zenith Dual Brite meets ENERGY STAR guidelines‚ reducing energy consumption․ It features a Dual Brite timer and automatic shut-off‚ enhancing efficiency and lowering utility bills․
8․1 Energy Star Compliance
The Heath Zenith Dual Brite Motion Sensor Light is ENERGY STAR certified‚ ensuring energy efficiency․ It meets strict guidelines when the Dual Brite function is off and the ON-TIME is set to 1 or 5 minutes‚ especially with 120W Max bulbs․ This certification helps reduce energy consumption and lower utility bills‚ promoting eco-friendly operation while maintaining high performance․
8․2 Power-Saving Features
The Heath Zenith Dual Brite Motion Sensor Light incorporates power-saving features like the Dual Brite timer and automatic shut-off․ It uses a photocell to disable lighting during daylight‚ conserving energy․ The ENERGY STAR certification ensures efficient operation when the Dual Brite function is off and the ON-TIME is set to 1 or 5 minutes․ These features help reduce energy consumption and prolong bulb life‚ making it an eco-friendly choice․
Warranty and Support
The Heath Zenith Motion Sensor Light Dual Brite is backed by a comprehensive warranty․ For assistance‚ contact customer support at 1-800-858-8501 or visit www․hzsupport․com․
9․1 Warranty Information
The Heath Zenith Motion Sensor Light Dual Brite is covered by a limited warranty․ A dated sales receipt is required for warranty claims․ The warranty covers defects in materials and workmanship for a specified period․ For detailed terms and conditions‚ refer to the warranty section in the manual or contact customer support at 1-800-858-8501․ Proper registration and maintenance are essential to ensure warranty validity․
9․2 Contacting Customer Support
For assistance with your Heath Zenith Motion Sensor Light Dual Brite‚ contact customer support at 1-800-858-8501 (English-speaking only)․ Support is available Monday through Friday‚ 7:30 AM to 4:30 PM CST․ Visit their website at www․hzsupport․com for additional resources‚ troubleshooting guides‚ or to submit inquiries․ Ensure to have your product model and purchase details ready for efficient service․
